1300Ton Hot Forging Press
1300Ton Hot Forging Press
1300Ton Hot Forging Press
Manufcturer : Hosung Korea
Year of manufacturing : 2006
Whole reconditioned mechanically and electrically in 2018
Servo loader, unloader with auto lubrication spary system (Make : Dongsan) was built and combined with this press in 2018
Dieset (Bolster, Mold holder) included
Dieset has a hydraulic mold clamping system
Good condition
* Specification
▪ Capacity : 1300tons
▪ Stroke : 225mm
▪ Stroke per minutes : 90
▪ Shut height : 640mm
▪ Slide adjustment : 8mm
▪ Slide size (LR x FB) : 880 x 880mm
▪ Bed size (LR x FB): 900 x 1050mm
▪ Main drive motor power : 75Kw
▪ Press weight : 80tons (approx)
▪ Technical manual available
