1000Ton Hot Forging Press
1000Ton Hot Forging Press
1000Ton Hot Forging Press
Manufcturer : JNH Press Korea
Year of manufacturing : 2015
Dieset (Bolster, Mold holder) included
Dieset has a hydraulic mold clamping system
Good condition
* Specification
▪ Capacity : 1000tons
▪ Stroke : 250mm
▪ Stroke per minutes : 85
▪ Shut height : 700mm
▪ Slide adjustment : 8mm
▪ Slide size (LR x FB) : 830 x 880mm
▪ Bed size (LR x FB): 970 x 1050mm
▪ Side Opening : 510 x 680mm
▪ Upper ejector : 25mm
▪ Lower ejector : 50mm
▪ Main drive motor power : 55Kw x 8P
▪ Press weight : 60tons (approx)
▪ Technical manual available
